| Name: | Innosilicon M30S 82t 92t 94t 106t M30S+ | Hashrate: | 82t 92t 94t 106t |
|---|---|---|---|
| Algorythm: | SHA-256 | Manufacturer: | MicroBT |
| Size: | 150 X 225 X 390mm | Chip Boards: | 3 |
| Chip Name: | Sam-sung | Chip Size: | 8nm |
| High Light: |
Innosilicon M30S,Asic Miner Innosilicon M30S,BTC mining machine M30S+ |
||
Innosilicon M30S 82t 92t 94t 106t M30S+ SHA256 ASIC BTC mining machine with psu
| Manufacturer | MicroBT |
|---|---|
| Model | Whatsminer M30S |
| Release | April 2020 |
| Size | 150 x 225 x 390mm |
| Weight | 10500g |
| Chip boards | 3 |
| Chip name | Samsung |
| Chip size | 8nm |
| Chip count | 444 |
| Noise level | 72db |
| Fan(s) | 2 |
| Power | 3268W |
| Voltage | 12V |
| Interface | Ethernet |
| Temperature | -5 - 35 °C |
| Humidity | 5 - 95 % |
In terms of appearance, the Innosilicon mining machine M30S adopts the classic and extremely simple barrel design in the industry, with a body size of 390x150x225mm and a weight of 10.5kg. On the basis of ensuring stable placement, the elongated body on all sides reduces the occupation of the left and right space to a minimum, facilitating the collaborative mining of multiple mining machines.
In order to ensure the heat dissipation capacity, except for the fan module, the fuselage of the Innosilicon mining machine M30S is made of all-metal materials, and the surface of the fuselage is preset with large-area cooling fins and ventilation holes. Metal grilles are installed on the surfaces of the two fans in the front (intake) and the rear (outflow), which can protect the fan blades and the hash board to prevent users from accidentally touching them.
In terms of interface, the main interface of Innosilicon Mining Machine M30S has only one Ethernet interface, one TF card firmware interface and one power interface. In terms of buttons, there are only 1 restart button, 1 IP address button, and 1 running status light module (red/green). The minimalist and professional design ideas have been implemented to the extreme.
Whatsminer M30S has 3 power boards inside, and each power board is equipped with dense ASIC chips. The aluminum alloy heat sink fins on both sides of the hashrate board are attached to the chip with silicone grease and fixed with 26 spring screws.
Computing power performance:
According to the official data of Bit Micro, the standard computing power of the Innosilicon mining machine M30S is 88TH/s±5%, the power consumption is 38W/T±5%, and the power consumption ratio is 38JT±5%.
The computing power, quality control, and energy consumption ratio of the Innosilicon mining machine M30S have reached the industry's first-class standards. Not only can it meet the mining demand after the third Bitcoin production halving, but it can also compete with Bitmain and Canaan. The latest products of established manufacturers such as science and technology are directly off the wrist. The sale of this mining machine may promote the lowering of the industry's average price.
